Key Features
History and Search Automatically save previously captured waveforms with the DLM3000HD series, up to 200,000 previously captured waveforms can be saved in the acquisition memory. Display one or all of the previously captured waveforms (history waveforms) on screen and perform cursor measurement, computation, and other operations. Users can analyze rarely-occurring abnormal signals even when an appropriate trigger condition is difficult to find because its waveform shapes are not constant. Multiple intuitive search methods are also available. For example, you can specify a rectangular zone that captures a part of a waveform on the screen, a zone that covers an entire measured waveform, or a polygonal zone. If you know a value of interest, such as an abnormal value of voltage or pulse width, you can search history waveforms using waveform parameters. Please read this page carefully to fully understand all product page elements.
| Product Price | ₵12,000.00 | ||
Click to add this item to cart. | |||
| SKU: | INT102 |
| Product Shipping |
|
Product Description
Ideal for Everyday Use by Engineers
Adaptability is key in the development of high-performance and intelligent power semiconductor technologies and mechatronics in modern electric vehicles, motor controls, and energy efficient electronic designs. With up to 16 bits high resolution, best-in-class startup speed, and high noise immunity this four-channel oscilloscope provides an extensive set of analysis features in a compact design.
Setting a New Standard for High Definition
- 4 analog channels, 8-bit logic
- Bandwidth: 350 or 500 MHz
- Sample Rate: up to 2.5 GS/s
- Vertical resolution: 12-bit
- High resolution mode: up to 16-bit
- Measurement memory: up to 1 GigaPoints
- History waveforms: up to 200,000 triggers
- Simultaneous Multi-Channel Measurements: Up to 16-bit logic + 6 channels
- Up to 8 channels with two connected DLM3000HDs via DLMsync
- IEEE1588 Synchronous Support
- Highly-Responsive, Intuitive 8.4in Touchscreen
- with Traditional Oscilloscope Control Panel
- Superior Noise Immunity
- Logic and Serial Bus Analysis
- Additional Math Channels
- Extensive Voltage Ranges
- Compact, Light, Portable
Key Specifications
12- to 16-Bit High Resolution
Compared to traditional 8-bit oscilloscopes, the DLM3000HD measures 12-bit vertical resolution all the time. With its high-definition, resolution improves up to 16-bits, providing 16x more detail than existing high-definition oscilloscopes. Its high-resolution mode enables detailed measurement of events such as ringing and overshoot with impressive accuracy.
Product Features
| Color | White |
| Size | Big |
| Weight | 130 lbs |
